Designed for maximum penetration and durability, this excavator ripper is built to break through hard ground, rip out stumps, and stubborn roots without flexing under pressure.
Built for Serious Work
30” base-to-tip (straight line)
1½” thick shank
Full boxed gusset design to eliminate mount flex
Weight: 250 lbs
Rated for excavators up to 20,000 lbs
Interchangeable mounting system
The reinforced, fully boxed gusset adds structural strength where most rippers fail — at the mount — giving you confidence when applying full breakout force.
Smart Tree-Cradle Design
The integrated tree cradle on the back serves two key purposes:
Helps keep the ripper centered on the tree while pushing it over
Keeps the attachment standing upright when unhooked for easier alignment during hookup
Built for serious excavation work, this heavy-duty root rake is designed to maximize digging performance, durability, and efficiency in land clearing and site prep applications.
Built for Strength
1½” thick digging tines for extreme durability
6 digging tines with 8” spacing for effective debris separation
9” digging tine depth for aggressive root penetration
3½” and 4” tube steel frame construction
¼” thick frame walls for added structural integrity
Total weight: 300 lbs to 400lbs depending on size.
Rated for excavators up to 20,000 lbs
This rake is engineered to withstand the torque and breakout force of excavators without twisting or flexing under load.
Designed for Easier Hookup
Two rear support ribs hold the rake slightly tilted upward when resting on the ground. This positioning makes pin alignment and attachment faster and easier during hookup.
Interchangeable Mounting System
The interchangeable mounting system allows compatibility across multiple excavator setups, giving you flexibility without sacrificing strength.
77 Steel Ripper Bucket
The 77 Steel Ripper Bucket combines the power of a ripper with the versatility of a bucket, making it the ideal attachment for tough excavation and land-clearing jobs. Built with 1-inch thick side plates and a replaceable tooth cap, it's designed to withstand years of hard use while keeping maintenance costs low.
The 14-inch wide profile delivers excellent penetration for trenching, ripping stumps and roots, handling rocks and logs, and breaking through hard-packed ground. Instead of switching between multiple attachments, the 77 Steel Ripper Bucket gives you one rugged tool that does it all.
Features
14" Bucket Width
1" Thick Side Plates
Replaceable Tooth Cap
Combination Bucket & Ripper Design
Heavy-Duty Welded Construction
Built for Trenching, Stump Removal, Rocks & Logs
77 Steel — One Attachment. Multiple Jobs. Built to Last.
The 77 Steel Excavator Grading Beam combines grading, spreading, and compacting into one heavy-duty attachment. Available in 48", 60", and 72" widths, it features an adjustable front cutting blade, a center secondary spreading blade, and an integrated rear compacting roller to deliver smooth, professional results with fewer passes. Precision laser cut, CNC formed, and proudly manufactured in the USA, it's built for contractors who demand speed, accuracy, and durability.
The 77 Steel Excavator Triple Ripper is built for maximum ripping performance on excavators up to 20,000 lbs. Weighing approximately 350 lbs and measuring 34 inches tall, 30 inches long, and 12 inches wide, it features three replaceable teeth for unmatched ground penetration and productivity. Ideal for land clearing, root removal, breaking hard-packed soil, and rocky terrain, its heavy-duty boxed construction delivers exceptional strength and durability. Precision laser cut, CNC formed, and proudly manufactured in the USA, the Triple Ripper is built to handle the toughest jobs.
This bucket features either straight edge or with teeth.
Straight Edge Great for: With Teeth :
Leveling ground Breaking up hard ground
Smoothing aggregates and soil Replaceable Tooth caps ( 23, 230)
Moving bulk material
Landscaping applications
Ditch maintenance
Slope shaping
Whether you're grading a pad or cleaning up a site, this bucket provides control, consistency, and a clean finished surface.
Sizes 14”, 24”, 36”, 48”
please reach out for custom sizes.
706-239-0462
Projects@77steel.net
Weight: Approximately 150 –350 lbs (varies depending on size and top plate configuration)
Interchangeable adaptor plate available
Built for aggressive digging and material separation, this ribbed bucket is designed to handle demanding excavation work while maintaining structural strength.
Heavy-Duty Construction
U.S. Built with U.S. Steel
½” solid, one-piece tines
8-piece frame construction
6” x ¾” thick cutting blade
3.5” tine spacing across 48” width
Interchangeable adaptor plate
Weight: 450–500 lbs (with plate)
The ribbed design allows material to separate while maintaining strength through the full frame. Built tough for contractors who expect their attachments to hold up under pressure.
The 77 Steel Excavator Twin Ripper is engineered for fast, efficient ground penetration and maximum durability. Weighing 300 lbs and measuring 34 inches tall, 30 inches long, and 8 inches wide, it's built for excavators up to 20,000 lbs. The dual-tooth design easily cuts through roots, hard-packed soil, and rocky ground while minimizing material disturbance. Featuring heavy-duty boxed construction, replaceable teeth, and precision laser-cut components, the Twin Ripper is designed and manufactured in the USA to deliver years of dependable performance.
The 77 Steel Excavator Smooth Rake is engineered for fast, efficient land clearing, brush removal, and debris handling. Built from heavy-duty steel and precision laser-cut components, it easily separates roots, rocks, logs, and brush while allowing soil to fall through the tines for cleaner, more productive operation. Whether you're clearing property, preparing a jobsite, or cleaning up storm damage, the 77 Steel Root Rake delivers the strength and durability professionals demand.
Available in 36", 48", and 60" widths, each rake is designed with optimized tine spacing for excellent material retention and maximum digging performance. Every attachment is CNC formed, professionally welded, and proudly manufactured in the USA.
77 Steel 9" Trenching Bucket
Designed for digging narrow, clean trenches with maximum strength and minimal material removal, the 77 Steel 9" Trenching Bucket is built for contractors who demand durability and performance. Featuring 1/2" thick side plates, this bucket is engineered to withstand tough conditions while maintaining its shape under heavy use.
With a 9-inch cutting width and an overall depth of 36 inches from the top of the bucket to the cutting edge, it provides excellent reach for utility work, drainage, irrigation, and foundation trenches. Its narrow profile reduces excavation time by removing only the material you need, helping increase productivity and reduce backfill requirements.
Features:
9" digging width
Heavy-duty 1/2" thick side plates
36" overall bucket depth (top to cutting edge)
Reinforced construction for long service life
Ideal for utility, drainage, irrigation, and foundation trenching
Built in the USA by 77 Steel
Convert your excavator into a versatile material handling machine with the 77Steel Excavator to Skid Steer Adapter. Designed with a universal skid steer quick attach interface, this adapter allows you to use a wide variety of skid steer attachments directly on your excavator.
The adjustable mounting angle lets you set the attachment to the position that best fits the job, improving visibility, grading accuracy, and attachment performance. Built from heavy-duty American steel, precision laser cut, CNC formed, and professionally welded, this adapter is engineered for years of dependable service in demanding environments.
